DS-PDEB1-EG2-WB

Datasheet: DS-PDEB1-EG2-WB

Feature

• Button: 1
• Tamper Protection: Front;Rear
• Environment Temperature Indicator: Support
• Signal Strength Indicator: Support

Interface

• LED Indicator: Blue(Alarm)

Transmission

• Technology: Tri-X Wireless
• Method: Two-Way RF Wireless
•  Frequency: 433MHz
• Security: AES-128 Encryption
•  Range(Free Space): 800m
• Frequency Hopping: Support
• Enrolling Method: Power up;Remote ID;QR Code

Electrical Characteristics

• Standard Battery Life: 3 years in work status (being triggered 20 times per day)
• Power Supply: Battery Powered
• Battery Type: CR2450 x 1
• Typical Voltage: 3V

General

• Operation Temperature: -10 °C to 55 °C (14 °F to 131 °F)
• Storage Temperature: -20 °C to 60 °C (-4 °F to 140 °F)
• Operation Humidity: 10% to 90%
• Dimension(WxHxD): 63.8mm × 63.8mm × 17.9mm
• Weight: 45.5g
• Mounting Method: Wall
• Application Scenario: Indoor, Green Keymat For Medical Application
